Details
Ruthless Progression
This totally redesigned P.Series gives riders of all sizes a jumping off point to a life on bikes. The lightweight, but tough alloy frame is designed to take all the hits and keep rolling—across all frame and wheel size options. Our approach to these robust bikes centers around delivering a simple, high-quality platform that's versatile for all riders, and packs in category-first features that make a difference to the rider.
Starting with the durable lightweight alloy frame, the new P.Series stands up to the demands of dirt jump progression. Its cables are internally routed, adding to its sleek presence and tangle-free riding.
• Lightweight, Specialized engineered rigid fork, geo corrected to 80mm of travel makes
fork upgrades easy.
• 19mm OD handlebars, plus short reach brake levers and grips sized for smaller hands
helps young riders stay in control.
• Specialized Kicker tires find grip anywhere, street, dirt, or at the skatepark.
SIZE | 20" |
---|---|
Chain-Stay Length (mm) | 320 |
Wheelbase (mm) | 840 |
Top-Tube Length (horizontal) (mm) | 449 |
Bike Stand-Over Height (mm) | 560 |
Seat-Tube Length (mm) | 265 |
Seat-Tube Angle (°) | 72 |
Fork Rake/Offset (mm) | 40 |
Front-Center (mm) | 520 |
Wheel Size (inch) | 20 |
Stack (mm) | 428 |
Reach (mm) | 310 |
Head-Tube Length (mm) | 90 |
Head-Tube Angle (°) | 68.5 |
B-B Height (mm) | 259 |
B-B Drop (mm) | 5 |
Trail (mm) | 61 |
Fork Length (full) (mm) | 380 |
Crank Length (mm) | 115 |
Handlebar Width (mm) | 600 |
Stem Length (mm) | 35 |
Saddle Width (mm) | 110 |
Seatpost Length (mm) | 200 |
Specs
Frame | Specialized P.1, A1 Premium Alloy, 20", Fully Butted Tubing, Tapered Head Tube, BSA 73mm BB Shell, 12x148TA Sliding Dropouts, Single Speed or Geared Compatible, 52mm CL, Internal cable routing, 30.9 Seat Tube, Dropper Post Compatible |
---|---|
Fork | Specialized A1 Alloy, 20" Rigid, Tapered Alloy Steer Tube, 15x110TA, 372mm Axle to Crown |
Rims | Specialized P.Series, 20", 32h, 26mm ID, Disc Brake Only |
Hubs |
Front: Alloy, 6-Bolt, 28H, 15x110 Boost Rear: Alloy, 6-Bolt, 28H, 12x148 Boost, 11-speed compatiable |
Spokes | Stainless, 14g |
Tires | Specialzied Kicker Sport, 20x2.1" |
Bottom Bracket | BSA 73mm |
Crankset | Specialized P.series, 52mm CL, 115mm Length |
Chainrings | 30T |
Cassette/Freewheel | 13T SS Cog |
Chain | KMC Z1, 1/2x3/32", Single Speed |
Brakes |
Front: Radius CX7, Mechanical Disc, 180mm Rotor Rear: Sram Level T, Hydraulic Disc, 160mm Rotor |
Handlebars | Mini Rise, Alloy Double Butted, 6-degree Backsweep, 600mm Width, 31.8mm , 19mm Bar End Diameter |
Tape/Grips | Specialized Trail Grips, 19mm bar end diameter, lock-on |
Stem | 3D-forged alloy, 31.8mm, 6-degree rise |
Seatpost | Specialized, 6061 alloy, 2-bolt clamp, 0mm setback, 30.9mm |
Saddle | Specialized P.series, Steel Rails |
Pedals | Specialized Platform Pedal |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Gloss Deep Marine/Purple Haze / 20-inch | 888818862719 | 91923-8120 | 210000016059 |
Satin Rusted Red Overspray/Blaze / 20-inch | 888818862702 | 91923-8020 | 210000016060 |
